HRVI-6HD 2nd Generation

Overview

The HRVI-6HD 2nd Generation is the latest version of our heritage line camera systems. It offers 4.6m GSD resolution imagery with a 70 km swath. It also has an hyperspectral option. The payload consists of three sub-units, the DCP (Dual Camera Payload) and two PLSU (Payload Support Unit), one attached to each of the DCP’s two optical heads.

Characteristics:
- Resolution: (PAN / MS) 4.6m / 9.2m @500 km
- Swath: 70 km @ 500 km
- Channels: 1 PAN +4 MS
- DPU: JPEG, 2 TB storage, CCSDS, Encryption
- On Orbit Focusing: Yes
- Size: 540 x 320 x 170 mm³
- Mass: 10.45 kg
- Design Life: 5 years

Specifications

Component Type
Camera/Imager
Form Factor
SmallSat
Dry Mass
10.45 kg
Average Power
N/A
Heritage
Yes
Status
In Production
