iOBC
Overview
The ISIS On Board computer (IOBC) is a flight-proven, high-performance processing unit based around an ARM9 processor with a speed of 400 MHz, making it one of the most capable on-board computers for CubeSats, currently available on the market within the same price range. Its pluggable daughter board offers additional flexibility and customizability by providing a wide range of extra interfaces for payloads, sensors or actuators in a compact form factor.
Specifications:
Mass: 94 grams mainboard
Dimensions: 96 x 90 x 12.4 mm
Power Consumption: 400 mW average
Power Supply: 3.3 V
Operating Temperature: -25 deg C to +65 deg C
Processor: 400 MHz 32-bit ARM9 processor
Volatile Memory: 64 MB SDRAM
Code Storage: 1 MB NOR Flash
Critical Data Storage: 512 kb FRAM
Mass Data Storage: 2 x 2GB high reliability SD cards for fail safe data storage (up to 32 GB on request) or 2x any size standard SD cards
Looking for more information or want to purchase?
Overview
- Name
- iOBC
- Subsystem
- CDH Subsystem
- Component Type
- On-Board Computer
- Form Factor
- CubeSat
- Heritage
- Yes
- Average Cost
- $5,200 to $8,090 USD
- Fiscal Year
- 2021
- Average Lead Time
- 2 to 3 months
Vendor Details
- Name
- Innovative Solutions In Space
- Website
- https://www.isispace.nl/
- Founded
- 2006
Vendor Request for Information Form
Specifications
- Subsystem
- CDH Subsystem
- Component Type
- On-Board Computer
- Form Factor
- CubeSat
- Dry Mass
- 0.094 kg
- Average Power
- 0.4 W
- Heritage
- Yes
- Status
- In Production
