NANOhpm-obc – RISC-V FT based OBC with CMM™ OBSW

Vendor profile

Overview

The NANOhpm-obc is a high-performance RISC-V on-board computer, designed for most demanding LEO applications.

NANOhpm-obc provides a versatile design in terms of variety of resources and available interfaces. The NANOhpm-obc is built on a robust NANOobc architecture, enhanced with significantly greater processing power, delivering 100 DMIPS at 50 MHz. It delivers Fault Tolerant NOEL-V processor (Cobham Gaisler - CAES) in peripheral rich SoC design. The NANOhpm-obc is delivered with flight proven NANOsky CMM Firmware framework, on top which application layer functions can be developed to suit any mission needs.

KEY FEATURES

• Fault Tolerant NOEL-V processor
• RISC-V 32-bit architecture
• Single precision FPU
• 256 MB DDR3 memory
• 4 Mbit NMV for TM storage (unlimited read/write endurance)
• Redundant 2Gb NAND Flash for mass storage
• Redundant CAN for TM/TC
• 2x High-speed LVDS or RS422/485 channels
• 8x GPIO (with multifunction support UART/SPI/TWI and OBT trigger)
• GNSS receiver on board (GPS / GLONASS / Galileo / BDS / QZSS )
• Compatible with the PC-104 form factor.

Looking for more information or want to purchase?

Contact now

Overview

Name: NANOhpm-obc – RISC-V FT based OBC with CMM™ OBSW
Vendor: SkyLabs
Subsystem: CDH Subsystem
Component Type: On-Board Computer
Form Factor: SmallSat
Heritage: Yes

Vendor Details

Name: SkyLabs
Website: https://www.skylabs.si/
Founded: 2016
Summary: SkyLabs is a space-technology oriented company providing miniaturized on-board data handling solutions and innovative approach to space engineering. Our primary focus is on high-tech, tailor-made solution development, including fault-tolerant hardware and software development, digital signal processing, radiation-hardened-by-design IP core development, fast prototyping, and space/ground segment communication. We are a vibrant team of electrical, mechanical and computing engineers and scientists providing services and technology solutions for the most demanding terrestrial and aerospace applications. By following the latest technology trends we provide innovative solutions with a proactive and creative design approach. Expertise & Competences • Awareness of harsh space radiation environment effect. • RT electronics, FT IP cores and ASIC designs. • Hardware accelerated approach. • Fail safe software development. • RF systems and signal processing. • Mechanical structures and systems. NANOsky avionics • Highly miniaturized cost-efficient avionics with fault-tolerant features. • Radiation hardened by design. • Constant current monitoring and limiting. • SEE immunity. • Innovative error mitigation techniques. • Selective component technology with flight heritage. • Sophisticated three-level FDIR policy. • EDAC protected memories/registers. • Redundancy on all critical functions and thoughtful component selection ensure robustness, • High reliability and availability of the platform. • Compliant with NANOsky CMM™ Software Development Kit AI@Edge support Highly miniaturized cost-efficient avionics with fault-tolerant features. Implementation of superior AI embedded algorithms directly on sub-systems is enabling onboard data analysis, decision-making, and efficient utilization of resources. Solutions for the most demanding applications with very high-performance needs. skyEGSE solutions Turn-key EGSE solutions that enables faster “Time-to-Space”. Cost efficiency, compatibility with major ground station service providers and security features make this an ideal solution for constellation missions. Various options of advanced EGSE equipment and software are available.
