xHF Comms - UHF/VHF Communications Module
Overview
The xHF Comms by TakeMe2Space is a communication module designed to facilitate robust and reliable communication between a satellite and a ground station. It operates in both the Very High Frequency (VHF) and Ultra High Frequency (UHF) bands, with the specific frequency determined by the configuration. The VHF channel operates at a frequency of 100-200 MHz, while the UHF channel operates at 300-500 MHz. This dual-band capability allows for flexibility in communication, depending on the mission requirements, environmental conditions, and regulatory constraints.
Looking for more information or want to purchase?
Overview
- Name
- xHF Comms - UHF/VHF Communications Module
- Vendor
- TakeMe2Space
- Subsystem
- Telecom Subsystem
- Component Type
- Transceiver
- Form Factor
- CubeSat
- Heritage
- N/A
- Average Cost
- $3,500 to $4,000 USD
- Average Lead Time
- 2 to 3 months
Details
- Antenna
- UHF
- Antenna type
- Turnstile
- Bandwidth
- 1.1 - 850 KHz
- EIRP
- 30 dBm
- Interfaces
- FD-CAN, RS-485, UART
- Max Symbol Rate
- 433333.33 Kbps
- Modulation
- FSK, GFSK, GMSK ,OOK
- Peak Power
- 7 W
- Processor
- ARM® Cortex®-M4 Microcontroller 32-Bit Single-Core
- UHF Frequency Range
- 300-500 MHz
- VHF Frequency Range
- 100-200 MHz
Vendor Details
- Name
- TakeMe2Space
- Website
- https://tm2.space/
- Founded
- 2024
- Summary
- TakeMe2Space is building in-orbit data centres to meet the soaring demand for AI compute. Space offers a sustainable and economic solution for this need. Our proprietary radiation shielding material lowers the cost of in-space compute by allowing terrestrial components in satellites. Global users can access these satellites via our space apps, OrbitLab and OrbitView, to run algorithms, use sensors, and control satellite orientation. Our indigenously designed and developed satellite hardware was proven on ISRO's PSLV C-60 through our mission, MOI-TD. We offer our compute and other subsystems developed along the way to the space community including satellite builders and Assembly-Integration-Test (AIT) companies.
Vendor Request for Information Form
Specifications
- Subsystem
- Telecom Subsystem
- Component Type
- Transceiver
- Form Factor
- CubeSat
- Vendor
- TakeMe2Space
- Dry Mass
- N/A
- Average Power
- N/A
- Heritage
- N/A
- Status
- In Production
