SS Sun Sensor - Medium

SS Sun Sensor - Medium image

Overview

OCE’s magnetomer uses a fluxgate sensor which measures the Earth's magnetic field strength and provides the relevant data for generating magnetic torque with the magnetorquer. The magnetometer is designed for real-time testing of the local three axis component of the magnetic field so as to provide precise magnetic field test data for geomagnetic field measurement, satellite platform attitude measurement and satellite residual magnetism and magnetic measurement. The product includes probes, line box, and the corresponding connector cables. The control and processor circuit board are all contained within the circuit box. The probe is used to sense three-axis magnetic field strength, which is converted to electrical signals and output to the magnetometer circuit. The circuit box is used to receive and process the magnetic field signal sensed by the probe and to output the magnetic field value in the form of an analog signal.

Looking for more information or want to purchase?

Overview

Name
SS Sun Sensor - Medium
Component Type
Sun Sensor
Form Factor
CubeSat
Heritage
Yes

Vendor Details

Name
OCE Technology
Summary
O.C.E. Technology supplies radiation-hardened system-on-chips, system-in-package memories, on-board computers, and custom parts. Its industry leading debug software accelerates development times thus reducing cost. The company’s branded products division include satellite subsystems from the Chinese space program.

Vendor Request for Information Form

Max. 1000 characters

Please include a detailed description in your message. This helps vendors to better understand your request.

Specifications

Component Type
Sun Sensor
Form Factor
CubeSat
Dry Mass
0.005 kg
Average Power
N/A
Heritage
Yes
Status
In Production
