STIM277H

Overview

STIM277H is a small, tactical grade, affordable, robust and reliable, ultra high performance (Bias Stability 0.3 deg/hr, ARW 0.15 deg/√h) 3 axis MEMS gyro module built into a hermetic package. The package is a hermetic aluminum enclosure with a glass-to-metal sealed electrical micro-d connector and a laser-welded lid to secure long-term hermetic operation. All parts are tested for fine and gross leak to conform to MIL-STD-883J, Class H.

An integrated 32-bit microcontroller enables flexible user configuration. Electronic axis alignment is standard.

Specifications

Component Type
IMU/IRU
Form Factor
CubeSat
Dry Mass
0.052 kg
Average Power
1.3 W
Heritage
N/A
Status
In Production
