STIM318

Overview

STIM318 is a small, tactical grade, low weight, high performance non-GPS aided Inertial Measurement Unit (IMU) with greatly improved accelerometer performance. STIM318 build upon the flight proven STIM300 that has years of successful flight heritage. It contains 3 highly accurate MEMS gyros, 3 ultra-high stability accelerometers and 3 inclinometers. The IMU is factory calibrated and compensated for temperature effects over its entire operating temperature range.

STIM318 is a cost-effective ITAR free solution for systems that only had FOGs as an alternative when reaching for the performance level of that STIM318 can offer.

Specifications

Component Type
IMU/IRU
Form Factor
CubeSat
Dry Mass
0.057 kg
Average Power
1.8 W
Heritage
N/A
Status
In Production
