STIM377H

Overview

STIM377H is a small, tactical grade, low weight, high performance non-GPS aided Inertial Measurement Unit (IMU) in a hermetic package. The package is a hermetic aluminum enclosure with a glass-to-metal sealed electrical micro-d connector and a laser-welded lid to secure long-term hermetic operation. All parts are tested for fine and gross leak to conform to MIL-STD-883J, Class H.

STIM377H contains 3 highly accurate MEMS gyros, 3 high stability accelerometers and 3 inclinometers. The IMU is factory calibrated and compensated over its entire operating temperature range.

STIM377H is a cost-effective ITAR free solution for systems that only had FOGs as an alternative when reaching for the performance level of that STIM377H can offer.

Specifications

Component Type
IMU/IRU
Form Factor
CubeSat
Dry Mass
0.055 kg
Average Power
1.5 W
Heritage
N/A
Status
In Production
